Session Error: The Rise & Risk of Electric Skateboarding Trailer

On Thursday September 15th, I’ll be live streaming my latest short documentary “Session Error: The Rise & Risk of Electric Skateboarding” followed by a Q&A. For those in the Michigan area who would like to attend the screening you can RSVP for FREE here:

https://www.eventbrite.com/e/session-error-the-rise-risk-of-electric-skateboarding-tickets-27339475106

Synopsis
On June 2, 2016, software engineer Robbie Small suffered a traumatic brain injury while riding an electric skateboard. This is his story.

“Session Error: The Rise & Risk of Electric Skateboarding” is a short documentary film that details the emerging popularity of high performance, electric skateboarding and the misconceptions about e-boarding risk and safety.

Total Running Time: 25 min.
Produced by Rik Cordero & Robbie Small
Directed, Shot & Edited by Rik Cordero
Produced by Arbor Day Pictures & A2ESK8
Doors open at 6:00pm
Screening begins at 7:00pm sharp followed by Q&A with the filmmakers
Food and refreshments will be served

Our Electric Skateboards Got Mobbed at Maker Faire Detroit

This past weekend, our local electric skateboarding crew A2ESK8 participated at Maker Faire Detroit, a family-friendly showcase of invention, creativity and resourcefulness, and a celebration of the Maker Movement.

maker00

Makers ranged from tech enthusiasts to crafters to homesteaders to scientists to garage tinkerers. About 25,000 people attended the event to check out ordinary individuals rolling up their sleeves to create inventive solutions for everyday needs.

maker01

Sometime last year I began to search for other DIY ESK8 builders so I created a Facebook group to draw others in which birthed A2ESK8 – Michigan’s largest social hub dedicated to the building of DIY electric skateboards. Our booth was graciously sponsored by our friends at Carvon Skates and Polar Pro whose products are seamlessly integrated into our local ESK8 culture of building and filming.

maker02

Attendees were able to get hands on with some of our boards as they were able to throttle and brake using our realtime display bench rig to test RPM, temperature and current.

maker03

For those were interested in the tech, we had live demos of VESC (Vedder Electronic Speed Control) and LiFePO4 battery assembly. We also provided insight on the open source community and the emergence of ESK8 as a major player in the personal electric vehicle movement.

maker04

We took turns riding the boards around The Henry Ford which provided a glimpse at what ESK8 feels like. Many of our riders describe ESK8 as an alternative to snowboarding and longboarding where you get a similar feeling of “flying” on the ground.

maker05

All around us roads are changing, structures go up and having a “spotter” who you are communicating with through Bluetooth intercoms creates a sense of gamified exploration. Every turn we make can be something new and its all about living in that moment with zero distractions. Essentially it’s meditative and can relieve any stress that’s built up throughout the day.

maker06

Who knows what the future holds for A2ESK8 but one thing will always remain clear – our mission is to combine safety, reliability, art and design to inspire others to be part of a growing DIY community that will innovate the electric skateboard industry.

emc2
product information button runplayback Carvon EMC2 Dual Hub Motor Electric Mini Cruiser

polarpro
product information button runplayback Polar Pro GoPro Frame 2.0 Professional Filter 6 Pack

phantom 3 filters
product information button runplayback Polar Pro DJI Phantom 4 / Phantom 3 Filter 6-Pack

Why I Built a Carbon Fiber Electric Skateboard Mini Cruiser


Shot exclusively with the LanParte LA3D Action Gimbal, DJI Phantom 3 and Polar Pro Filters

My original DIY Electric Mini Cruiser Skateboard still holds up quite nicely even after 6 months of hard riding and natural wear and tear. But as with all things DIY, parts can always be upgraded. One key feature that I wanted to improve upon was weight, so once again, I researched the right combination of components to make an already awesome commute even better. I’ve nicknamed this build – the A2ESK8 Mini Cruiser.

hi5ber02

My original 29″ mini cruiser was the perfect size thanks to the unique design of the now discontinued Jet Spud deck. But I wanted to do something different, which is why I chose the Hi5ber Ion 30 mini cruiser deck. Hi5ber has built a great reputation for manufacturing the best carbon fiber longboard decks available. They are lighter and stronger than typical wooden longboards which create a more controlled, responsive experience for the rider.

hi5ber01

The Ion 30’s design is the definition of stealth with it’s ultra thin rails that gradually curve thicker towards the wheelbase. The added benefit is an enhanced wheel clearance that looks so damn futuristic. Other than the low weight, the characteristics of the Ion 30 include high rigidity, high tensile strength, corrosion resistance and fatigue resistance. And unlike wood, carbon fiber doesn’t warp when exposed to water.

ion30
product information button runplayback Hi5ber Carbon Fiber Ion 30

hi5ber_sidewinder

Before electricfying the Ion 30, I tested it out with Gullwing Sidewinder II trucks alongside 72mm ABEC11 Freerides and it was a blast. That combination of an ultra lightweight carbon fiber deck and double kingpins was so much fun I was a little hesitant to throw electronics on there. But my curiousity got the best of me so I got to work.

battery01

The next step in weight reduction was the battery. My original build contained the 10s3p Enertion Space Cell, a wonderful battery pack, but 30 cells demand a lot of real estate in the wheelbase for a small mini cruiser deck. With a wheelbase of 16.25″ on the Hi5ber, I knew I had to figure out another power solution.

battery03

I ended up creating a custom 12s1p LiFePO4 battery pack with the help of my friend Landon who is an electronics wizard. LiFePO4 batteries are the safest type of lithium batteries as they will not overheat, and even if punctured they will not catch on fire. The cathode material in LiFePO4 batteries is not hazardous, and poses no negative health or environmental hazards. Due to the oxygen being bonded tightly to the molecule, there is no danger of the battery erupting into flames like there is with lithium-ion. We used 12 cells in series for a total voltage of about 36v. Paired with a BMS, voltage display, charge port and power button, the pack ended up having a more compact size – perfect for the Hi5ber deck.

battery02

Once again I designed a custom 1/8″ ABS enclosure using my homemade vacuum former. This time I wanted the buttons to be located on the side of the enclosure as flush as possible. This created a more pleasing appearance that complimented the look of the carbon fiber. The length of the enclosure came out to 11″ and width at 5″. This meant plenty of room to spare on the Ion 30 wheelbase.

apone01
product information button runplayback A2ESK8 Apone V1 Electric Skateboard Enclosure

nano_remote

Another big upgrade I made was swapping my original Torqueboards 2.4ghz Mini Remote with an even smaller 2.4ghz Nano Remote that features a thumb throttle instead of a trigger throttle. As far as how it feels in my hand, it’s pretty awesome. Granted, I’m not a big guy but it’s the right size for stealth in the city. It’s as if they took the best features of the Yuneec EGO and Boosted Boards remote and put it into a no frills casing. I like the short throw, knob throttle which is a much better design than Boosted’s long throw thumb dial and trigger button. Shout out to Kaly over at ESK8 builders for the hookup on this remote.

ollinboard01

The only components I ported over from my original build are the Ollin Board VESC and the Carvon V2 Single Hub Motor. Because of months of wear and tear and a few moisture issues, Landon and I decided it was best to clean the VESC up with some gentle scrubbing and a coating of anti-corrosion spray. Even so, the VESC is still going strong with no issues or errors – a testament to Ollin Board’s high quality manufacturing practices.

mini01

My Carvon V2 Single Hub Motor was upgraded with authentic 90mm ABEC11 Flywheels and is really the backbone of my entire mini cruiser build. I’ve put the hub motor through the ringer in every harsh road condition imaginable and it continues to perform flawlessly. Carvon continues to push the boundaries of eboard drive trains and I look forward to seeing what they do next with their V3 hub motor design and EVO series.

mini02

Dialing in the VESC settings is critical for creating a safe and fun mini cruiser. My original build was capable of hitting 31 mph but the sweet spot for a board this small is around 15-18 mph – more than enough for carving through a dense city filled with intersections and pedestrians. Also, the 12s LiFePO4 battery delivers a stronger punch than my 10s lithium ion with a more stable discharge and minimal voltage sag. As much as I enjoy releasing the full power and speed from a DIY eboard, there’s something quite satisfying about taming a mini cruiser eboard that has the ability to hurl you but won’t because you’re keeping it on a leash. More importantly, this build never feels like it’s struggling or straining and that kind of confidence transfers into longer range and fun, safer rides.

mini03

Skating the A2ESK8 Mini Cruiser around the city proved to be a blast. On FOC mode with the Carvon V2 hub motor, the sound is nearly silent. The ultra light Hi5ber Ion 30 board makes acceleration from standstill fantastic and it really feels like your riding on some kind of space age material because of how responsive it is. Carbon fiber handles bumps slightly differently than wooden decks but in a good way because vibrations don’t transfer as much harsh energy to your body. Oh and did I mention how light this thing is? Seriously I’ll take carbon decks over wood any day of the week.

mini04

DIY electric skateboard builds have been getting better and better in just a few months yet there are still just a handful of 30″ and under DIY mini cruiser builds. Perhaps it’s a bit of a stigma to purposely limit your top speed on a smaller deck but I feel like it’s our responsibility to be ambassadors of this technology everytime we step on a board. I’ve already seen friends who’ve hurt themselves on eboards and in almost all cases, the problem was either an inexperienced rider or a road obstacle and not a board failure. Going over 25 mph instead of 13 mph on a non electric board meant crashes that have caused broken bones and serious concussions. Believe me, I’ve had first hand experience with this and it’s made me a very visible advocate for eboard helmet safety.

makerfaire

This mini cruiser was not designed to be a land missile and it shows. It’s become the ultimate conversation starter whenever I ride in the city because I’m seriously just having fun. The weight reduction made a huge difference and carrying it on public transportation is even easier. If you’re in the Detroit area at the end of July, check out this mini cruiser build in person at the Detroit Maker Faire where will have an A2ESK8 booth and demonstrations. For more information on the products I used to create the video above, please check out the links below.

group

lanparte_bh
product information button runplayback Lanparte LA3D Detachable 3-Axis Handheld Gimbal

polarpro
product information button runplayback Polar Pro GoPro Frame 2.0 Professional Filter 6 Pack

My New Film “Force Touch” Is Streaming For Free


Force Touch is now streaming for FREE

Check out my latest short film “Force Touch”, shot entirely with the Varavon Birdycam Lite and the Panasonic GH4. Synopsis below:

When four friends discover a smartphone that takes pictures of the future, things go from bad to worse as their darkest secrets are revealed. Written, Shot & Directed by Rik Cordero. Produced by Arbor Day Pictures & Neutral Zone. Executive Produced by Nancy Mitchell.

5-19-16_Force_Touch_Movie_Premiere-50
Photo Credit: Katie Alexis

5-19-16_Force_Touch_Movie_Premiere-14-1
Photo Credit: Katie Alexis

The sold out screening at the historic Michigan Theater was a huge success. The power of independent storytelling, community and inspiration is a potent combo and it was evident from the positive feedback from the audience. A big thank you to our sponsors – Camera Mall, Aspen Mics and Polar Pro for the wonderful raffle gifts, Neutral Zone, Sunday Afternoon Pictures, YPSI24, our photographer Katie Alexis and our friend Jason Buchanan who conducted the interview below about the making of “Force Touch”.

I sense an influence from The Twilight Zone here. In particular, the episode “A Most Unusual Camera”, was that show an influence on you as a storyteller? Could you talk about some of your influences in writing and directing?

Yup that episode of the “Twilight Zone” was a major influence, especially with the voiceover narration that provides just enough exposition to pull you into the story. Charlie Brooker’s “Black Mirror” was also a strong influence as I wanted to explore the consequences of modern technology on a specific group of young people who aren’t very likeable. I imagined these characters had big dreams in college which never fully materialized. It’s like that weird time in your early 20’s when you’re not young enough to be dependent yet not old enough to be jaded by the grind.

My wife Nancy (Executive Producer of the film) and I, moved from New York City to Ann Arbor last July. We shot a ton of music videos and commercials during our time there but the work life balance sucked. Once we moved, the creative quality of our lives improved almost immediately through meeting many diverse folks with common interests.

With more time to focus on storytelling, I came up with the idea of “Force Touch” and my goal was to capture elements of the college culture here from an outsider’s point of view. I’m a college football fan but maybe not to the degree as some of my friends who have lived here their entire lives so I wanted to explore those emotions and how they would bounce off the characters in the story. Also Ann Arbor was a new canvas for me to employ a layer of sci-fi and technology which is another passion of mine.

5-19-16_Force_Touch_Movie_Premiere-6
Photo Credit: Katie Alexis


Neutral Zone Promo video produced by Arbor Day Pictures

Can you expand on the role that the Neutral Zone played in producing the short? What was it like working with them?

I was introduced to Lori Roddy and Mary Moffett at Neutral Zone through Dug and Linh Song. After getting the tour of the facilities I was instantly inspired to contribute something to their video program that’s run by Alysha Schlundt-Bodien. Once we set our shoot dates, I reached out to Neutral Zone to help produce it. From our script rehearsals with the actors to camera assisting, lighting and sound, we provided some Neutral Zone Teens first hand experience with independent filmmaking. It was a tough shoot, especially since our first day landed on a major snowstorm but we made it through and hopefully some of the kids will stick with it.

force_bts02
Force Touch pre production meeting at Neutral Zone, Ann Arbor

As a relatively new transplant to the area, what are your impressions of the local filmmaking scene? What do you like? Anything you wish you could find but haven’t?

I met the majority of our cast by participating in last year’s YPSI24 24 hour film competition and it was one of the best experiences I’ve had in a long time. There’s a special sense of camaradrie and collaboration here that’s been missing for awhile in New York City. It’s easy to stay busy in NYC but most video creatives including myself were often stuck hustling multiple gigs just to pay the bills. There’s a better work life balance here that’s very refreshing and reminds me about why I got into this business in the first place – to share stories and stay inspired.

5-19-16_Force_Touch_Movie_Premiere-69
Photo Credit: Katie Alexis

Can you talk a little about your work with Duo Security?

Duo Security reflects a lot of why the Ann Arbor community is appealing to me. Our CEO Dug Song, Creative Director Pete Baker and Multimedia Specialist Martin Thoburn have embraced my thirst for living a creative life which motivates me to think about creative video solutions for Duo. Things like recruiting videos to brand awareness and case studies are not often big priorities at most tech companies but Duo is unlike any other company I’ve worked for. Our creative team can go toe to toe with some of the best creative agencies in any major city and it’s a testament to the forward thinking goals of the leadership here.

One thing that most filmmakers have in common when it comes to doing the corporate grind is – how much of my artistic integrity do I have to give up just to fit in? I’ve retained 100% of my artistic integrity since working here and that comes from having an office culture that doesn’t force you to conform to tradition.

My value at Duo may not have a direct measurement as someone in Sales or Engineering and while metrics and procedures are important, nothing is more valuable than offering up creative solutions that keep our street cred intact. There’s a reason why our website doesn’t look like an out of the box template or why our videos entertain some of the most successful tech people in the world. We must be doing something right.

5-19-16_Force_Touch_Movie_Premiere-79
Photo Credit: Katie Alexis

Lastly, are there any video projects in development that you can talk about?

At Duo, I’m working on a huge marketing stunt called “Duo in Space” where we will launch a weather balloon equipped with a phone and prosthetic finger that will perform a Duo 2-Factor Authentication push from close to 120,000 feet above the earth. In my spare time, I’m sharing DIY techniques on my blog runplayback.com and building electric longboards with my crew A2ESK8.

5-19-16_Force_Touch_Movie_Premiere-35-1
Photo Credit: Katie Alexis

trippler
product information button runplayback Polar Pro Trippler 3-in-1 Tripod/Grip/Pole

birdycam_lite
Varavon Birdycam Lite 3-Axis Camera Gimbal


product information button runplayback Panasonic GH4 4K Video Recording

Lanparte LA3D 3-Axis Action Gimbal First Impressions

Action gimbals are all the rage these days, especially at this year’s NAB Show, yet the one that really stood out to me was the Lanparte LA3D gimbal for the GoPro. Cosmetically, it’s similar to the Came TV Action and the Ikan Fly X3-Go but if you look further, it has some really well thought out design features that make it the best action gimbal out right now.

la3d_2

The most standout feature on the LA3D is the detachable mounting system. With my previous Came TV electric longboarding rig, weight distribution was often a problem as mounting the entire gimbal to the end of a painter’s pole created a very front heavy rig that would be tricky to handle especially when traveling at high speeds. With the LA3D you can mount only the gimbal on the top of a boom pole via a 1/4-20 thread and hold the battery/control stick in another hand via a wire control cable. For electric longboarding where you need have one hand on the transmitter, I’d recommend keeping the control stick in your pocket or strapping it to your boom pole with some velcro straps. It would have been nice if Lanparte had added a 1/4-20 thread on the controller side as well to keep things even more modular. Some other interesting ways to mount the LA3D are using a Polar Pro Trippler Grip Pole or a standard GoPro chest mount and head mount to keep things centered.

la3d_3

The LA3D holds two 18350 Li-Ion batteries but you can attach a 2″ tube extender and use two larger 18650 Li-Ion batteries for up to 8 hours of power. The three modes are pretty standard – follow mode that pans and tilts to your wrist direction, semi-follow mode where tilt is locked but can be adjusted using the control pad and locked mode where tilt and pan adjustments are made manually on the control pad. The best integrated mode feature is probably inverted mode which enables you to turn the gimbal completely upside down. This makes booming from high angle to low angle action shots super seamless. Stay tuned for Part 2 where I’ll demonstrate some LA3D footage. If you have any questions hit me up in the comments.

lanparte_bh
product information button runplayback Lanparte LA3D Detachable 3-Axis Handheld Gimbal

trippler
product information button runplayback Polar Pro Trippler 3-in-1 Tripod/Grip/Pole

My Homie Jeff Made A 45 MPH Electric Longboard!

Just wanted to share a new video series I’m developing titled “Duo Meet Your Maker” which profiles local hackers, tinkerers, hobbyists, and the tech-savvy makers to learn about their processes and highlight the things they create. My goal with this series to look beyond the gadgets themselves to explore the people behind them and what makes them tick. My first subject is Jeff Plott, a local mechanical engineer, who built a 45 mph electric longboard! Yikes! If you’d like to know more about how I shot those action shots check out my electric longboarding action rig here.

Konova Launches the portable, travel friendly SunJib S700 – NAB 2016

NAB 2016 coverage continues with a look at the SunJib from Konova. This unique, portable jib system has a one touch, telescopic, single arm design and an automatic self leveling system for smooth booming shots. This keeps the subject horizontal which allows you to focus on the momentum of your panning moves. The SunJib is also compatible with Konova’s highly regarded slider system to create very unique, low angle sliding / boom shots. The included transport bag also makes it very travel friendly for all situations. Traditional jibs have always been a hassle for me to build and break down but the the Konova SunJib definitely hits that sweet spot of portability and professional grade camera moves.

We spoke with Peter from Konova for an in-depth demonstration. For more information on when the SunJib will be released, please visit Konovaphoto.com

Polar Pro Launches New Drone Accessories – NAB 2016

Our friends at Polar Pro continue to dominate the industry with their always evolving professional grade product line and innovative ideas. And with a recent appearance on ABC’s Shark Tank, their business has lept tremendously with a $1 million investment by Mark Cuban and Robert Herjavec.

At this year’s NAB Show, we checked out Polar Pro’s latest drone accessories for the DJI Phantom 3, DJI Inspire 1, 3DR Solo as well as the Trippler – a compact tripod / grip / pole combo for action cameras and mobile phones. With my frequent forays into electric longboarding, the Trippler has instantly become my go-to accessory for capturing the moment.

inspire 1 filters
product information button runplayback Polar Pro DJI Zenmuse X3 Filter 3-Pack

phantom 3 filters
product information button runplayback Polar Pro DJI Phantom 4 / Phantom 3 Filter 6-Pack

phantom 3 lights
product information button runplayback Polar Pro LED Light Kit for DJI Phantom 3 Quadcopter

phantom 3 landing gear
product information button runplayback Polar Pro Landing Gear for DJI Phantom 3

phantom 3 gimbal lock
product information button runplayback Polar Pro Lens Cover / Gimbal Lock for Select Phantom 3 Quadcopters

phantom 3 gimbal guard
product information button runplayback Polar Pro Gimbal Guard for Phantom 3 Professional / Advanced / Standard

solo lights
product information button runplayback Polar Pro Headlight and Taillight Kit for 3DR Solo Quadcopter

solo prop guards
product information button runplayback Polar Pro Prop Guards for 3DR Solo Quadcopter

trippler
product information button runplayback Polar Pro Trippler 3-in-1 Tripod/Grip/Pole

I Made an Action Cam Rig for Electric Longboarding

After racking up hours of DIY electric longboarding videos, I’d like to share some of the tools that I use for capturing high speed action. If you recall from my original DIY Electric Longboard build article, I was initially inspired to use an eboard as a dolly when paired with my camera gimbal. As I got into high speed riding with eboards I needed a way to capture the action and feel of a ride through inventive, hard to reach camera angles. Here’s a very compact setup that’s easy to handle while in the midst of all the action.

20160330_220400

ACTION CAM
The Xiaomi Yi has been my main action camera for quite some time. At around $80 you get a wi-fi action cam that records 2k videos with natural colors, definition and solid low light ability. The quality is comparable to the GoPro Hero3+ and the best feature is the 1/4-20 female thread on the bottom which allows better compatibility for clamps and rigs instead of GoPro’s proprietary mounting system. The Wi-Fi app is super easy to use for live preview and remote recording. You could pick up three Xiaomi Yi’s for the price of one GoPro Hero3+ which is a value that’s really hard to beat.

Price: $78

xiaomi
Xiaomi Yi Action Camera with Wi-Fi

20160330_220452

ACTION CAMERA GIMBAL
The Came-TV 3-Axis Action Gimbal is a 32-bit gimbal that features brushless motors with Encoders. Encoders are often used in Robotics for highly accurate monitoring of motor position. This helps prevent motors from losing synchronization and skipping steps, provides important information about frame and camera angles, increases battery life, increases torque and the precision of stabilization.​ The gimbal is constructed from aluminum alloy, weighs in at a very light 300 grams, has a 1/4-20 female thread and is compatible with the Xiaomi Yi.

Price: $300

came
product information button runplayback CAME-TV CAME-Action 3-Axis Gimbal

20160330_220426

PAINTER POLE ADAPTER
This DIY Painter Pole Adapter is designed to connect to the top of a standard paint pole and turn it into a very long monopod. It’s made of CNC machined aluminum with an anodized black finish and has a 1/4-20 male stud to fit perfectly with the Came Action Gimbal. Alternately, you can use this with a small ball head for accessories or even as a microphone boom pole.

Price: $15

adapter
DIY Boom Painter Extension Pole Adapter

20160330_220313

PAINTER POLE
The Shur-Line Easy Reach 60″ Adjustable Extension Pole extends from 30″ to 60″ with almost no flex. It also features an ergonomic handle and is great for capturing hard-to-reach shots. With a painter’s pole I’m able to get the camera as close to the action as possible. One shot I like to do is having a rider cut in front of me as I raise the pole from bottom to top to create a booming effect.

Price: $18

painter pole
Shur-Line 60 in. Adjustable Extension Pole

TECHNIQUE
Mileage may vary depending on your stance on the eboard but since I ride goofy and use the eboard trigger remote on my right hand – I keep the painter pole tucked under my left shoulder while balancing the whole rig on my left hand. This position lets me use my whole body to maneuver the camera while still being able to lean and carve on the road.

For safety, I’d advise wearing full safety protection (helmet, pads, etc) and always keep your eye on the road through peripheral vision. Communication is also key so be sure to direct the rider and let them know if you see something cool. You’ll know that you’re nailing your technique when you forget that you’re filming and are focused on composition.

CONCLUSION
Electric longboards are super fun to ride and combine the feeling of longboarding and snowboarding except you can eboard anywhere with large, smooth pavement. With speeds that hover around 30mph and over, having a compact, lightweight rig is essential to capturing the rush of excitement that comes from eboarding. Also get creative – shoot some drone shots, capture B-Roll of your homies or clamp the action cam on the board itself. If you have any questions or suggestions hit me up in the comments below!

carvon
Carvon Electric Mini Cruiser (Pre-Order)

My New Royce 5’9″ Video Was Shot Entirely with the Varavon Birdycam Lite

Check out my latest music video for Royce 5’9″ titled “Which Is Cool”, shot entirely with the Varavon Birdycam Lite and the Panasonic GH4. The concept is that Royce can hardly contain his honest thoughts which start filtering into the real world through his music. Here’s my treatment for the song:

We open on Royce and his brother walking out of their SUV and into a convenience store in Detroit. Inside the store are various extras – a skinny dude wearing feminine tight clothes, a girl dressed in baggy, masculine clothes, rich businessman, street dude, hooker, etc. Each time he calls out these personality types in his thoughts, we’ll cut to their actions. As this is happening Royce will walk through the store, gathering various items to purchase.

Royce’s performance will be gradual. It will begin as just his thoughts so his lyrics will be translated through his body language and looks which causes him to rap in spurts. The extras will interact with him, offended that they are being called out yet are too afraid to do anything about it.

Suddenly we cut to Royce and his brother purchasing the items at the counter. In the background all of the extras are staring at them in silence, emotionless and offended. We follow Royce and his bro into the SUV. Royce turns the radio on and suddenly we…

Cut to black.

royce

birdycam_lite
Varavon Birdycam Lite 3-Axis Camera Gimbal


product information button runplayback Panasonic GH4 4K Video Recording

I Built Another DIY Electric Longboard With More Power

V2_05

My original DIY Electric Skateboard is quite possibly one of my favorite things I’ve built so far and the feedback has been phenomenal. Every ride is an opportunity to discover inventive ways to capture the board on video. However, the communal experience of riding with other people is where the real fun begins. The performance gap between my DIY Single Hub Eboard and my Yuneec EGO is too wide so the only solution was to build another board. Do I really NEED more than one? Absolutely not. But the shared experience of riding with others is priceless.

20160313_203655

DOING THE DUAL

I had the option to either replicate my original DIY Single Hub or go for something a little different. Perhaps a single belt drive or a dual setup. I ended up choosing a dual hub motor system. There’s a bit of a perpetual debate on belt drive vs. hub motors and it always comes down to personal preference. The stealth and coasting ability of the Carvon Single Hub is incredible. But the best feature to me is that it can withstand some of the harshest conditions imaginable. Harsh conditions during a Michigan Winter include rock salt, potholes, uneven pavement, snow, black ice, etc. Once I decided on using Carvon Dual Hubs for my next build, choosing the rest of my parts was fairly simple.

CHOOSING THE PARTS

20160207_104826

JET TOMAHAWK “PEACE OUT” DECK
I knew this build would not be a mini cruiser like my last one, but I loved the quality of my Jet deck so I wanted to find something similar but with a longer wheelbase. I ended up going for the Jet Tomahawk because of it’s freeride design and variable wheelbase from 23.75″ to 28.25″. The Tomahawk shares similar wheel wells like my Jet Spud but has more of an aerodynamic, missle-like shape. When it comes to choosing a deck, Muirskate is a great resource for all things longboards. Shout out to Scott!

Price: $79.95

tomahawk
Jet Tomahawk “Peace Out” Deck

20160221_211242

CARVON V2 DUAL HUB MOTOR + MATCHING TRUCKS + WHEELS SET
As I mentioned, the durability of the Carvon Hub is what did it for me. Jerry at Carvon knew how much fun I was having on a single hub but said a dual would be even more of a blast. Since I pretty much committed to a big boy board, I ended up going with massive 97mm wheels which is recommended for 10s-12s Li-Po packs. Like last time, the Carvons arrived on time with a clean, professional build all around – heavy duty 2250W brushless outrunner motors, 10″ black trucks with matching black anodized motor sleeves and ceramic bearings. There’s been some questions about why the motor isn’t completely hidden inside of the urethane and I would assume it’s to create the actual feel of riding on a wheel as opposed to riding on a motor. I haven’t tried the thin urethane hubs on an Inboard or Stary but I’d be hesitant about riding those anywhere but pristine, paved roads in California. Where I’m from, the roads are tough and I have no hesitation blasting through them with Carvons.

Price: $599

carvon02
Carvon V2 Dual Hub Motors + Matching Trucks + Wheels Set

20160309_212606

ENERTION 10S SPACE CELL BATTERY
The Enertion 10S Space Cell has been so reliable and convenient that getting another one was no question. I haven’t had the chance to perform any range tests yet but it’s more than enough juice for a full day of riding on single hub and it will be interesting to compare the duration with a dual hub. The new version of the Space Cell also features an improved power switch and Jason’s customer service is top notch.

Price: $343.38

enertion02
Enertion 10S Space Cell Battery

20160309_212747

OLLIN BOARD COMPANY VESC – OPEN SOURCE ESC SPEED CONTROLLER
I doubled down on the Ollin Board Company’s VESC, still the best electronic speed controller created specifically for electric skateboards by Benjamin Vedder. Like I said, I’ve been riding hard in single digit Michigan weather in some of the most adverse conditions ever and have had no problems with the VESC at all. Honestly I don’t even think about it, which is a testament to the quality (heavy duty wiring, clean soldering, military grade, gold plated PCB’s, firmware testing) and is also coated for moisture and corrosion protection. The price on the Ollin Board VESC has gone up a bit but with the warranty and repair guarantee, it’s well worth it. Also be sure to pick up a CANBUS Connector to power the VESC’s together.

Price: $165

ollinboard02
VESC – Open Source ESC Speed Controller

Price: $5

canbus
CANBUS Connector for VESC

y-harness

FLITE TEST XT60 POWER Y-HARNESS
This 14AWG Y-Harness comes with presoldered XT60 connectors and is used to connect the dual VESC’s to the Space Cell.

Price: $7

y-harness
Flite Test XT60 Power Y-Harness

diyelectric01

TORQUEBOARDS 2.4GHZ MINI REMOTE CONTROLLER
Once again, I went with TorqueBoards 2.4Ghz Mini Remote from DIY Electric Skateboard. I’ve dropped it a few times and it’s still going strong. And it really does seem to last forever on only 2 double A batteries.

Price: $50

diyelectric02
TorqueBoards 2.4Ghz Mini Remote Controller

V2_01

V2_02

V2_03

20151227_102520

MISCELLANEOUS
Some odds and ends that I needed to complete my build.

$4.95 – Khiro 1/4″ Shock Pad Large Skateboard Risers

$4.95 – DBS Dank Bolts 1.25″

$6.19 – CCNS Neoprene Sheet 1/4” 12″x12″ Self-Adhesive

2 x $1.18 – 2 x #8-32 x 1 in. Phillips Flat-Head Machine Screws (5-Pack)

2 x $1.18 – 2 x #8-32 Stainless Steel Machine Screw Nut (4 per Pack)

$1.18 – #8 Zinc-Plated Steel Flat Washer (30-Pack)

THE ASSEMBLY

20160207_110820

20160207_132852

Like last time, I prepped the Jet Tomahawk deck by sanding away the paint job and spray painting it with glossy black. Covering those raw wooden wheel wells also looks a little better in my opinion.

20160313_205332

Once the VESC’s arrived I programmed it with the BLDC Tool here and tweaked some of the settings based on my previous build. A few things changed when switching over to a dual configuration. Here’s my settings that I used for each VESC.

MOTOR CONFIGURATION
Motor Max: 60.00
Motor Min: -30.00
Bat Max: 15.00
Batt Min (Regen): -12.00
Absolute Max: 130.00

CURRENT CONTROL
Startup Boost: 0.030

APP CONFIGURATION – GENERAL
Controller ID: Input “0” for VESC 1 and “1” for VESC 2
Enable Send status over CAN
Enable PPM

APP CONFIGURATION – PPM
Enable Multiple ESCs over CAN
Enable Traction Control

20160313_205311

Then, I binded the TorqueBoards remote to the receiver. Be sure to bind it properly to enable fail safe. If not, the board will go full throttle when you turn off the remote which is a major safety hazard. Next I added a JST cable to VESC 1 and the CANBUS Connector to connect VESC 1 and VESC 2. I also added some hotglue to all the connectors to prevent the connection from coming loose. Finally I added some velcro on the bottom of the VESC’s and the receiver. This will keep things secure inside of the enclosure.

20160313_205558

Next I prepped the Enertion Space Cell battery by adding velcro to the top. I found three strips placed equally across the length of the battery was enough.

20160313_205301

On the other side I added weatherstripping as a cushion. This side faces the skateboard deck so it’s important to have a little bit of cushioning to guard against vibrations.

20160313_205514

Next I prepped the RunPlayBack enclosure with corresponding velcro strips for the battery, VESC and receiver. I’m really happy with the size of this enclosure and the two piece design. Everything fits like a glove, especially the VESC’s.

20160313_205018

I carefully placed the Space Cell into the enclosure, making sure to align the power button, charge port and voltage display with the corresponding holes and connected the VESC’s with the Y-Harness. I also added a small flap of rubber as a cover.

20160313_203605

The Carvon Hub Motor and wheels were next. I picked up some 1/4″ Khiro shock pads and 1.24″ DBS Dank Bolts to mount the trucks to the deck. Finally, with everything in place I secured the enclosure using #8-32 machine screws, washers and nuts from Home Depot.

20160313_203938

CONCLUSION

Although my original DIY single hub eboard gave me the confidence to attempt another build, moving up to a dual build was no simple task. By doubling the major components, everything had to be bigger and beefier – from the choice of my deck to wheelsize to the enclosure. Once complete, I realized I created a beast – a literal land missle that dwarfs the nimbleness of my single hub board. I’m not quite sure I could use this as a daily cruiser but for the times when I have a lot of open road to let loose, this is the perfect build, especially as a weekend warrior.

20160313_203706

However, no matter how you slice it, moving up to a dual build isn’t cheap. Doubling the price of a VESC and hub motor presents a challenging value for those who are looking to get into DIY. Starting on a single hub build is more affordable and will definitely give you the confidence to move into a dual build if you crave more power.

20160313_203830

In my first article, I said that building a DIY electric board made me a better person and I still believe it. In only 2 months I’ve been able organize a local DIY eskate group called A2ESK8, engage in interesting conversations with the online DIY community as well as local tech and maker folks who find electric longboards fascinating. Right now the big barrier of entry is the price. But like drones and other electric vehicles, once manufacturing costs go down and battery technology improves, eboards will become more accessible. Until then, pushing the limits of emerging technologies is a blast and now that I have a second board, it will make that experience even better. So whose ready to ride? #A2ESK8

The Aspen Mics Belt Clip Completes My Zoom H1 Recorder

I don’t think I’ll ever get rid of my Zoom H1. For the price, it’s simplicity and quality has not really been matched even after all these years. However, the one feature that many Zoom H1 owners have gotten used to is the lack of a belt clip. Sure we’ve used all sorts of clamps, arms, and even the old “drop it in the pocket” method to mount the thing. Now, with the Aspen Mic Belt Clip, the Zoom H1 finally feels “complete”. Where have you been all my life?

20160225_144532

aspen
Aspen Mics Belt Clip for Zoom H1 Handy Recorder

zoomh1
product information button runplayback Zoom H1 Ultra-Portable Digital Audio Recorder

Warm Weather Means DIY Electric Skateboard Cruising

When it hits 57 degrees in February in MICHIGAN, you must take full advantage. 🙂

carvon02
Carvon V2 Single Hub Motor + Matching Trucks + Wheels Set

enertion02
Enertion 10S Space Cell Battery

ollinboard02
VESC – Open Source ESC Speed Controller

sulaco03
RunPlayBack Sulaco V1 Enclosure

How I turned my Ztylus iPhone into a DSLR Killer

Ztylus has been releasing some of the best iPhone accessories for quite some time and their latest product, the premium Z-Prime Lens Kit is no exception. The Z-Prime claims to be a professional grade solution for serious photographers. But I’m mostly into video so in the clip above, I pair it with the Varavon Birdycam Lite to see if a Ztylus equipped iPhone could produce professional DSLR-style results. In short, I was blown away.

IMG_8104
Ztylus Z-Prime Telephoto Lens for iPhone 6

Both the wide and telephoto lens contains 5 glass elements in 4 groups that enable corner to corner sharpness with ultra low distortion. Packaged with the two lenses is the iPhone Metal Series Case, a lens carrier, a pouch and lens cloth. Once again, Ztylus has reinvigorated the power of the iPhone. Be sure to click the banner below to receive 25% off all Ztylus products with our special RUNPLAYBACK referral code.

ztylus_banner

ztylus
Ztylus Z-Prime Lens Kit for iPhone 6

birdycam_lite
Varavon Birdycam Lite 3-Axis Camera Gimbal

SMART_BRACKET
product information button runplayback Dot Line SMARTbracket Smartphone Tripod Adapter

717_baseplate
Custom Fancier 717 Quick Release Adapter Base

717_qr
WF717 Replacement Quick Release Plate

Here’s a Manual on a DIY Electric Skateboard

Took another ride with my DIY Electric Skateboard and my buddy Robbie did a manual on the Carvon V2 Single Hub Motor. I had no idea it could do that. 🙂

carvon02
Carvon V2 Single Hub Motor + Matching Trucks + Wheels Set

enertion02
Enertion 10S Space Cell Battery

ollinboard02
VESC – Open Source ESC Speed Controller

sulaco03
RunPlayBack Sulaco V1 Enclosure

My DIY Electric Skateboard Hit 31mph!

Here’s another cruising video with my DIY Electric Skateboard. This time we hit 31mph on the Carvon V2 Single Hub Motor. Pretty sure that once we find some paved asphalt we can go even faster. Till then, stay tuned!

carvon02
Carvon V2 Single Hub Motor + Matching Trucks + Wheels Set

enertion02
Enertion 10S Space Cell Battery

ollinboard02
VESC – Open Source ESC Speed Controller

sulaco03
RunPlayBack Sulaco V1 Enclosure

Here’s What 28mph on an Electric Skateboard Feels Like

My obsession with DIY Electric Skateboards is at an all time high at the moment and as promised, here’s a follow up video of my DIY build cruising through a college campus parking lot courtesy of my boy Patrick. After a few weeks of optimizing my VESC based on the Carvon V2 Single Hub Motor and Enertion 10S Space Cell, I came up with the best all purpose BLDC Tool setting for this configuration:

Motor Max: 60.00
Motor Min: -30.00
Bat Max: 30.00
Batt Min (Regen): -12.00
Absolute Max: 130.00

In BLDC mode, we hit a top speed of 28mph despite the rock salt, pot holes snow puddles and rough terrain on these Michigan roads. My RunPlayBack Sulaco V1 Enclosure was definitely put the test but held it’s own and protected the electronics from the elements. Check out the video above to get some more insight on how I make these things.

20160130_131200

I was able to film Patrick while riding the Yuneec E-GO but it was nearly impossible to keep up with him. The torque of the E-GO’s belt drive has a bit more throttle snap than a VESC + hub motor combo but it’s simply no match when it comes to the top speed and coasting ability of the Carvon. Once you taste the speed of a DIY Electric Skateboard, it’s really hard to go back. I will conduct some range tests when the weather gets better but for now, I may need to build another electric board just to film this one. Stay tuned!

carvon02
Carvon V2 Single Hub Motor + Matching Trucks + Wheels Set

enertion02
Enertion 10S Space Cell Battery

ollinboard02
VESC – Open Source ESC Speed Controller

sulaco03
RunPlayBack Sulaco V1 Enclosure

How I Built a DIY Electric Skateboard and Became a Better Person

rik01

Full disclosure – as a kid, I’ve always enjoyed cruising around on a skateboard, mainly because I was terrible at doing tricks and too worried about getting hurt. Naturally, I gravitated towards computers and electronic hobbies from RC cars to drones and eventually Miniquad FPV racing. Fast forward to present day – the popularity of personal electronic vehicles has grown and with it – the electric skateboarding community which combines the gratification of DIY tinkering with a broader communal experience.

first-skateboard

My earliest memories of electric skateboards were of metal behemoths fitted with lead batteries like something out of a science fiction movie. These days, parts have gotten smaller and slimmer which have allowed manufacturers such as Boosted and Yuneec to carve a out a very unique market of consumers who are not just skaters or tech nerds but those who are looking for alternate modes of transportation. To be fair, someone using an electric skateboard for the first time looks pretty ridiculous but those who fully embrace the technology make it look they are having more fun in life than everyone else.

rik-ego

YUNEEC EGO

I was first introduced to the Yuneec E-GO by Emm from Cheesycam. Paired with a gimbal, we used it as a camera dolly for super smooth tracking shots. While the experience was fun, I didn’t have an immediate gut reaction to purchase, which is what typically happens when Emm shows off some new gear. I was intrigued, but the price point kept me at a distance. It felt a little gimmicky, like a big boy toy for guys my age who don’t like to hurt themselves.

ego
Yuneec E-GO

ego01

After about a year, I started seeing electric vehicles crop up around town and I began to feel left out. I was compelled to get my own big boy toy. And since I live about 2 1/2 miles away from my office, I figured an eboard would be the perfect way to commute. So with a little money saved I bought a used Yuneec E-GO display unit from eBay and immediately customized it with a new paint job and lights.

ego02

The E-GO is a rock solid entry level board, perfect for those who want to get their feet wet with electric skateboarding with little maintenance. Ask any hardcore DIY eboard builder and the Yuneec is not really a part of the conversation. But compared to a Boosted board, the E-GO has a very pleasant price tag for it’s components – nothing more, nothing less. It maxes out at 13mph which is slow for most but very reasonable for downtown city commuting where there’s more obstacles, unpredictable terrain and limited straightaways.

diy-tools

DIY ELECTRIC SKATEBOARDING COMMUNITY

Initially I thought about upgrading the E-GO to push it’s performance but after some research, it felt a little risky to modify a board whose only fault was being reliable. Like I never felt “cheated” by the E-GO if that makes sense. Plus having a production board to study for design research is always a good thing. Next, I started lurking in the Endless Sphere and ESK8 Builders forums, a cornucopia of knowledge for all things related to electric skateboarding. One thing that stood out to me was the pleasant attitude exhibited by many of the stakeholders in the community. Compared to some of the guys in Miniquad FPV groups, this was like a breath of fresh air. This is how I took my first plunge into DIY eboards.

dremel

FINDING THE PARTS

Every DIY eboard currently relies on components developed by many companies springing up to serve the market. These companies are developing batteries, writing code, engineering motor systems and figuring out pieces of technology at every point in between. This is a constantly evolving scene with DIY’ers providing some valuable nugget of R&D research hidden in posts across two major forums. It’s deep, but not alienating if you dedicate the time. With about a month of lurking, I felt I was caught up with the technology to make informed purchases. One thing to keep in mind is that many of these products are built by DIY’ers for DIY’ers which means its best to do your homework before hitting them with a barrage of questions. This isn’t like shopping for a sweater at Macy’s. Like all communities, it pays to play.

support

Supporting these guys with a purchase or two puts your skin in the game and as a customer they will give you personal attention and support for your build. You’ll need to have patience as products are made to order. My expected delivery times were off by about a week or two but since I placed my orders before Christmas and New Year, it was understandable. Waiting is hard. Really hard. But on the flipside, having something made to order feels special. Essentially, having a good customer attitude can mean the difference between someone going through the motions, versus someone really giving that extra attention to detail and a once over for quality control. I won’t get too wrapped up in specific components as parts will evolve way past what this article can provide but I can detail what informed my purchases which are entirely shaped by my personal needs.

jet01

CHOOSING THE PARTS

JET RADAR SERIES SPUD NIPS LIP DECK
I found this board through posts by Torqueboards and Siggs from ESK8 Builders. It’s 29″ length with a 21.25″ wheelbase seemed like the perfect size for my body dimensions and commuting distance. The nearly 40″ length of the Yuneec E-GO was comfortable but definitely a hassle for taking it on a bus or other form of public transportation. One thing that worried me was the rather large wheel wells and extreme concave but more on that later.

Price: $65.95

jet02
Jet Radar Series Spud Nips Lip Deck

carvon01

CARVON V2 SINGLE HUB MOTOR + MATCHING TRUCKS + WHEELS SET
To stay within my parameters of a stealthy, low key look, I went with a single hub motor from Jerry at Carvon. Carvon’s website FAQ answered all of my questions in regards to the advantages of hub motors and up to date photos of customer builds. Jerry was really helpful with shipping times and let me know that mounting the Carvon on the 29″ Jet Spud deck was possible but challenging due to the short wheelbase. Not one to shy from a challenge, I placed my order a week later and when it arrived, the product looked even better in person than the pictures. This may seem like common sense but being on the fence or wishy washy can only go so far when it comes to DIY. Once you soft commit to a purchase, be honest and follow through. It goes a long way to establishing a solid customer relationship.

Price: $299.00

carvon02
Carvon V2 Single Hub Motor + Matching Trucks + Wheels Set

enertion01

ENERTION 10S SPACE CELL BATTERY
Jason at Enertion Boards has been developing and innovating within the electric skateboard scene for quite some time and it shows. From complete builds to individual components, Enertion is proof of concept that DIY and ready to run solutions can co-exist peacefully. So when it came time to choose a power solution, I knew the Enertion Space Cell was the best bang for the buck hands down. Without getting too deep into battery comparisons, the 10S Space Cell is a self contained unit with a battery management system, power button, charging port and voltage display. Jason was also kind enough to give me advice on my components, measurement specs for my enclosure and overall encouragement to see my build through. It’s almost like he’s on a personal mission to outfit every man, woman and child on earth with an electric skateboard and I look forward to where he takes Enertion by next year.

Price: $314.87

enertion02
Enertion 10S Space Cell Battery

ollinboard01

OLLIN BOARD COMPANY VESC – OPEN SOURCE ESC SPEED CONTROLLER
The VESC is currently the best electronic speed controller created specifically for electric skateboards by Benjamin Vedder. Jeramiah at Ollin Board Company was another helpful resource for providing recommended settings on my build and constant updates on the VESC’s features. Once it arrived, the VESC quality was top notch with heavy duty wiring and clean soldering all around. Like a master chef preparing an expensive meal, Jeramiah uses military grade, gold plated PCB’s along with a re-flow oven for soldering components and various stages of firmware testing to ensure maximum efficiency.

Price: $120.00

ollinboard02
VESC – Open Source ESC Speed Controller

diyelectric01

TORQUEBOARDS 2.4GHZ MINI REMOTE CONTROLLER
I wanted an affordable, reliable, small remote so I went with this TorqueBoards 2.4Ghz Mini Remote from DIY Electric Skateboard. It isn’t fancy and is not really in the same league as slick production board remotes but it seems to last forever on 2 double A batteries and well – it just works like hell. With it’s small compact receiver, zero dropouts and transmission errors, this remote had my attention but now has my confidence. TorqueBoards is also very active on social media so sharing your build with him there is a quick and easy way to get immediate feedback.

Price: $50.00

diyelectric02
TorqueBoards 2.4Ghz Mini Remote Controller

sulaco01

sulaco02

sulaco03

RUNPLAYBACK SULACO V1 ENCLOSURE
To house all of these electronics I created my own DIY vacuum former oven that was inspired by Psychotiller from Endless Sphere and James Bruton from XRobots. Using feedback from Jason at Enertion and Jeramiah at Ollin Board Company, I created an enclosure code named the Sulaco V1 that is designed to house the Enertion 10S Space Cell, a single VESC and a standard 2.4ghz receiver. No more, no less. The specs are L: 20″ W: 8″ H: 2″ and features 1/8″ thick ABS plastic for lightweight performance, flexiblity high impact resistance, and added durability. Since I live right next door to a major ABS plastic supplier I can provide these at a good cost.

Price: $40

sulaco03
A2ESK8 Sulaco V1 Enclosure

shrink

MISCELLANEOUS
Here’s a few odds and ends that I needed to complete my build.

$4.95 – Khiro 1/4″ Shock Pad Large Skateboard Risers

$4.95 – DBS Dank Bolts 1.25″

$13.79 – MOB Grip Super Coarse Longboard 30 Grit 11″x40″ Griptape

$7.99 – 180 pc Rubber Grommet Assortment Set Firewall Wiring Electrical Wire Gasket Kit

$5.95 – 5 Pairs XT60 Male & Female Bullet Connectors Plugs For RC Hobby Lipo Battery

$6.49 – 127pc Heat Shrink Wire Tubing Assortment Wrap Electrical Connection Cable Sleeve

$6.19 – CCNS Neoprene Sheet 1/4” 12″x12″ Self-Adhesive

$4.70 -Small 13 X 23 X 1/16 Mechanics Shop Non Slip Black Rubber Tool Box Drawer Liner

$11.99 – Cowles Products/Black StyleGuard edge trim

2 x $1.18 – 2 x #8-32 x 1 in. Phillips Flat-Head Machine Screws (5-Pack)

2 x $1.18 – 2 x #8-32 Stainless Steel Machine Screw Nut (4 per Pack)

$1.18 – #8 Zinc-Plated Steel Flat Washer (30-Pack)

assembly01

assembly02

THE ASSEMBLY

As I waited for parts I decided to prep my deck by sanding away the sweet Jet Spud Lips design and spray painting it with glossy black. I figured the artwork would be covered with my enclosure so I didn’t feel too bad.

assembly03

assembly04

Next I added the MOB grip tape which is super coarse and probably too extreme for most folks. My hand actually started bleeding laying this stuff down so I threw on some work gloves. Ouch.

bldc01

bldc02

bldc03

Once the VESC arrived I programmed it with the BLDC Tool here and tweaked some of the settings based on the VESC FAQ found on ESK8.

assembly05

Once that was done, I binded the TorqueBoards remote to the receiver, then connected it to the VESC with a JST cable that was provided by Ollin Board Company. I added a ziptie as a cable lock to prevent the connection from coming loose and squeezed some hotglue to both the VESC and receiver for extra safety. Loose connections are a safety hazard so be sure to test the strength of every wire. If it can be pulled out with little force, it’s best to start over and do it right. Also adding some velcro on the bottom of the VESC and receiver will help keep things in place once you house it in the enclosure.

assembly06

Next I prepped the Enertion Space Cell battery by adding velcro to the top. I found three strips placed equally across the length of the battery was enough.

assembly07

On the other side I added a few strips of 1/4″ Neoprene as a cushion. This side faces the skateboard deck so it’s important to have a little bit of cushioning to guard against vibrations.

assembly08

Next I prepped the RunPlayBack enclosure with corresponding velcro strips for the battery, VESC and receiver. I can’t stress how important it is to have an enclosure that fits your electronics like a glove. Everything should be firmly enclosed and not swishing around like loose change in a jar.

assembly09

I carefully placed the Space Cell into the enclosure, making sure to align the power button, charge port and voltage display with the corresponding holes.

assembly10

Next I added the VESC and receiver by first pulling the motor wires through the holes and securing everything into the velcro. Once I was satisfied with the fit, I connected the VESC to the battery and added a small flap of rubber as a cover.

assembly11

You can get creative here and add an entire sheet of neoprene and rubber across the whole enclosure like the Yuneec E-GO battery system. Mileage will vary depending on your deck design and weather proofing needs. I highly doubt I’ll be riding mine through inclement weather so I didn’t go too crazy.

assembly12

The Carvon Hub Motor and wheels were next. I picked up some 1/4″ Khiro shock pads and 1.24″ DBS Dank Bolts to mount the trucks to the deck. Similar to the Yuneec E-GO design, the rubber shock pads are great for added flexibility and a smoother ride.

assembly13

I then mounted it all to the board, ensuring that each screw was tightened equally. I didn’t go crazy here, just wanted to get the tension secure.

assembly14

Finally, with everything in place I secured the enclosure using #8-32 machine screws, washers and nuts from Home Depot. There’s many different ways to mount an enclosure to a deck. Most folks like using tee-nuts for a cleaner finish and as a faster way to pop the enclosure on and off. I personally don’t mind the extra time using nuts and washers and with the crazy curvature of the Jet deck, I needed a little more play in the mounting holes.

assembly15

CONCLUSION

From my initial DIY product inquiries on 12/7/15 to 1/18/16, it took me approximately 41 days to complete the build. Slap on the downtime during holiday season and the process took much longer than expected. Yet the results were well worth it. There were a few times when I hit some speed bumps, particularly in the vacuum forming process where each failed pull felt like I got the wind knocked out of me. Like my brief time spent with Miniquad FPV’s, there were moments that zapped my creative energy. I wondered why was I spending all of my time on a glorified big boy toy while everyone else around me was living in the moment. It’s like, why didn’t I just buy a Boosted Board Dual Plus and call it a day?

rik02

Fortunately, with the help of a loving supportive family and encouragement from friends, this build became more than just some kind of self serving prophecy. With DIY electric skateboards, there’s an immediate gut reaction when you see one. Like the kid inside all of us suddenly leaps through the soul in our eyes and peeks through smiling. Once I tapped back into that emotion, everything made sense. Sharing each technical step with my 6 year old daughter and seeing her wide eyed reaction brought me back to reality. I didn’t make this build for me. I made it for anyone who ever felt weird in school. Who felt more comfortable tinkering on their computers and in their garage than on the football field. The minute you understand you can build something, however you get there, you’ll want to improve it and share it with the world. Once you DIY, you’ll never be the same again. Hit me up in the comments if you’d like to discuss and stay tuned for part 2 where I actually take this thing on the streets.
